Name: Model 60 Marine Disc Brake Repair Kit
Brand: Dexter Axle
SKU: DEX-071-B16-00
Price: 82.19 USD
Availability: InStock

Product Overview

Model 60 M/C Repair Kit | Disc Brakes

Launch with confidence knowing your boat trailer is equipped with the ultimate stopping power. The Dexter Axle Model 60 M/C Repair Kit for disc brakes provides everything you need to maintain or restore peak braking performance, ensuring safe and controlled stops every time you haul your precious cargo. Upgrade your braking system and experience the peace of mind that comes with reliable, dependable stopping power, even in challenging conditions.

Key Features

**Complete Repair Solution:** This comprehensive kit includes all the essential components for effective brake maintenance or repair, saving you time and money.
**Designed for Dexter Disc Brakes:** Specifically engineered for Dexter Axle's high-performance disc brake systems, ensuring seamless compatibility and optimal performance on boat trailers.
**Corrosion Resistant Components:** Built with durable materials to withstand harsh marine environments, maximizing lifespan and minimizing maintenance.
**Enhanced Safety:** Restore or maintain optimal braking performance for confident stops, even with heavy loads, steep inclines, or adverse weather conditions.
**Easy Installation:** Designed for straightforward installation, minimizing downtime and getting you back on the water faster.

What's in the Box

Master Cylinder
Gasket
Orifice Connector
Hex Bolt (3/4" long x 1/4" diameter)
Lock Washer (1/4" diameter)
Diaphragm-Style Filler Cap
Master Cylinder Cover

Specifications

Brake/Axle Capacity['8,000 lbs. TORFLEX® or Sprung suspension E-Z LUBE®, standard grease or oil lubrication', '7,000 lbs. TORFLEX or Sprung suspension E-Z LUBE, standard grease or oil lubrication', '6,000 lbs. TORFLEX or Sprung suspension E-Z LUBE, standard grease', '3,500 lbs. TORFLEX or Sprung suspension E-Z LUBE, standard grease']

Rotor['E-coated gray, vented, cast iron and hub piloted', 'E-coated gray, vented, cast iron integral one-piece hub and rotor', 'E-coated gray, vented, cast iron and hub piloted', 'Zinc coated']

Caliper['Ductile iron fixed caliper system, (4) 1-7/8" pistons', 'Ductile iron fixed caliper system, (4) 1-7/8" pistons', 'Ductile iron fixed caliper system, (4) 1-7/8" pistons', 'Ductile iron slider caliper system, 2-1/8" piston']

Caliper Attaching Bracket['Ductile iron, 4-bolt flange mounting pattern', 'Ductile iron, 5-bolt flange mounting pattern', 'Ductile iron, 5-bolt flange mounting pattern', 'Ductile iron, 4-bolt flange mounting pattern']

Hub Group['8 studs on a 6.50" circle 9/16" - 18, or 5/8" - 18 studs', '8 studs on a 6.50" circle 1/2" - 20, or 9/16" - 18, or 5/8"- 18 studs', '6 studs on a 5.50" circle 1/2"- 20 studs', '5 stud on a 4.50" circle 1/2"- 20 studs']

Wheels['16", 16.5" and 17.5" diameter wheels', '16", 16.5" and 17.5" diameter wheels', '15", 16" and 16.5" diameter wheels', '14" and 15" diameter wheels']

Brake Pads['Semi metallic lining compound', 'Semi metallic lining compound', 'Semi metallic lining compound', 'Semi metallic lining compound']

Fluid Displacement['.90 cu. in.', '.90 cu. in.', '.90 cu. in.', '.25 cu. in.']

Brake Fluid['DOT 3 or 4', 'DOT 3 or 4', 'DOT 3 or 4', 'DOT 3 or 4']

Disc Brake Performance['26,000 in-lbs of brake torque output when tested using 1,600 psi of hydraulic input pressure', '24,000 in-lbs of brake torque output when tested using 1,600 psi of hydraulic input pressure', '18,000 in-lbs of brake torque output when tested using 1,600 psi of hydraulic input pressure', '11,000 in-lbs of brake torque output when tested using 1,600 psi of hydraulic input pressure']
